Cable Protector Defender Mini

  • Cable Protector Defender Mini
  • compact, non-slip cable protector made of black, recyclable polyurethane
  • yellow polyethylene lid with high warning effect and secure closure
  • patented, self-cleaning lid hinge
  • 3 channels: 1 channel 35 x 35 mm, 2 channels 35 x 30 mm
  • load bearing capacity approx. 2t / 20 x 20 cm
  • fire resistance class B2 (DIN 4102), DEKRA-certified (DIN 31000, EN 61537)
  • resistant against oil, acid, solvents and petrol
  • reliable protection for cables and personnel for indoor and outdoor use
Technical Details

Width1.00 m
Height0.048 m
Depth0.290 m
Weight4.652 kg
Width channel 135 mm
Height channel 130 mm
Width channel 235 mm
Height channel 235 mm
Width channel 335 mm
Height channel 330 mm

CAD drawing

Cable Protector Defender Mini – CAD-Zeichnung (PDF)

Transport

Packaging Unit: max. 22 items per Euro skeleton container

Areas of use
Cable Protector Defender Mini – 3 small cable channels

The flat, compact, 3-channel cable crossover with integrated connector plugs and non-slip base provides optimum support on a wide variety of floors. Separately available end ramps (male/female) ensure safe and orderly insertion and removal of cables. Defender Mini cable protectors withstand a load of 2 tonnes on an area of 20 x 20 cm, so they are suitable for light vehicles, trolleys and pedestrians.

Defender Mini cable protector can be used at carnival events, trade shows, exhibitions, shopping centres and storage facilities as well as in theatres, studios and TV stations. Not suitable for road traffic.
